Toggle, Specification Grade, Back and Side Wired Switch

This Hubbell Wiring Device-Kellems toggle switch is designed for heavy-duty, specification-grade electrical applications. It operates as a three-way switch with a maximum current rating of 5 amperes at 24V DC, suitable for precise lighting control and other low voltage switching needs. The switch features back and side wiring options, making it adaptable for various installation requirements in electrical distribution and lighting solutions.

Specifications

• Manufacturer: Hubbell Wiring Device-Kellems
• Manufacturer Part #: CSB320RLV
• Configuration: 3-Way
• Operating Current: Maximum of 5A @ 24VDC
• Color: Red
• Front Material: Thermoplastic
• Base Material: Thermoplastic
• Contacts: Silver Alloy
• Terminal Screws: Brass
• Mounting Bridge: Steel, Zinc Plated
• Terminal Accommodations: #14 AWG min. - #10 AWG max. solid or stranded copper wire only
• Operating Temperature: Max. continuous 75°C; Min. continuous -40°C without impact
• Width: 2.000 in
• Product Weight: 1.5 lbs
• Country of Origin: China

Features

• Maintained Contact
• Thread cleaning captive mounting screw
• Automatic self-grounding stainless steel staple
• Back and side wired for flexible installation
