THOMAS & BETTS ICS75-1 AL SERV ENTR SPLICE A:1/0 B:4SLD - Insulated Aluminum Service Entrance Splice

The THOMAS & BETTS ICS75-1 is an insulated aluminum service entrance compression splice designed for standard conductor splicing applications. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable connections in wire and cable systems. This splice supports aluminum-to-aluminum or aluminum-to-copper conductor connections and is engineered to withstand all-season environmental conditions.

Specifications

• Material: Aluminum
• Connection: Compression
• Insulation: Yes
• Conductor Range: End A: 1/0 ACSR, 1/0; End B: #6 ACSR, #6 STR, #4 SOL
• Number of Conductors: 2
• Product Weight: 12.0000
• Mounting: None
• Environmental Conditions: All Seasons / Conditions
• Manufacturer: Thomas & Betts
• Manufacturer Part #: ICS75-1
• UPC: 783786102471
• Application: For Standard Conductor Splice

Features

• Constructed from aluminum for high conductivity
• Prefilled with oxide inhibitor to prevent oxidation and moisture ingress
• Color coded with marked strip lengths, installation die codes, and compression locations for easy identification and installation
• Tough stabilized nylon sleeves resist installing-tool pressure and provide reliable 600 V insulation
• Complies with ANSI C119.4 standard when properly installed
• RUS accepted for utility use
• Colored end caps simplify identification
