THOMAS & BETTS ICS71-1 AL SERVENTR SPLICE A:1-2STRN B:4SLD Electrical Splice Connector

The THOMAS & BETTS ICS71-1 is an insulated aluminum compression splice designed for standard conductor splicing applications. It is suitable for electrical distributors and lighting solutions requiring reliable wire and cable connections. This splice supports aluminum-to-aluminum or aluminum-to-copper conductor connections and is ideal for use in all-season environmental conditions, making it applicable for a wide range of switchgear and electrical distribution systems.

Specifications

• Manufacturer: Thomas & Betts
• Material: Aluminum
• Connection Type: Compression
• Insulation: Yes
• Number of Conductors: 2
• Conductor Range: End A: #2 ACSR, #1 to #2 STR; End B: #6 ACSR, #6 STR, #4 SOL
• Application: For Standard Conductor Splice
• Environmental Conditions: All Seasons / Conditions
• Mounting: None
• Product Weight: 25.0000 (units not specified)
• Manufacturer Part #: ICS71-1
• UPC: 783786102433

Features

• Constructed from aluminum for high conductivity
• Prefilled with oxide inhibitor to prevent oxidation and moisture ingress
• Color coded and marked for easy identification with strip lengths, installation die codes, and compression locations
• Insulated with tough stabilized nylon sleeves providing reliable 600 V insulation
• Complies with ANSI C119.4 standards when properly installed
• Suitable for aluminum-to-aluminum and aluminum-to-copper conductor connections
• RUS accepted
