Features

• Mercury Free
• Classic Styling
• Premier White®
• The T87K heat only works with 2 or 3 wire heat-only systems

Specifications

• Hazmat Information: Button cell contained in equipment, Lithium metal button cells only contained in equipment, excepted per PI970
• Application: Heat Only
• Dimensions (in.): 3 11/16 in. diameter x 1 3/4 in. deep
• Dimensions (mm): 94 mm diameter x 45 mm deep
• Item Type: Product
• Mounting: Round
• Electrical Ratings: 20 to 30 Vac
• Frequency: 50 Hz; 60 Hz
• Stages: 1 Heat
• Operating Humidity Range (% RH): 5 to 90% RH (non-condensing)
• Supply Voltage: 20 to 30 Vac
• Power Method: Battery assisted power stealing
• Sensor Element: Thermistor
• Accuracy (F): ± 2 F
• Accuracy (C): ± 1 C
• Color: Premier White®
• Switch Type: Relay
• Terminal Designations: R, W, Y
• Setting Temperature Range (F): 40 F to 90 F
• Cycles per Hour: Adjustable 1, 3, 5, 9
• Heat Current: 0.02A to 1.0A running

Downloads

Owners Manual

Technical Documents

Accessories

• 50000066-001/U
• 50010944-001/U
