TECH LIGHTING 700TTSORGW TT-SUPPORT OUT RIG WO/CONN WH Lighting Support

The TECH LIGHTING 700TTSORGW TT-SUPPORT OUT RIG WO/CONN WH is a support outside rigger designed to cantilever T~TRAK™ single-circuit track lighting systems up to 36 inches from a wall. This product is intended for indoor dry locations and is field-cuttable to accommodate specific installation requirements. It serves as a structural support component within lighting solutions, ideal for electrical distributors and switchgear suppliers working with wire and cable for track lighting installations.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part #: 700TTSORGW
• Product Weight: 1.4 lbs
• UPC: 756460973650
• Suitable Location: Indoor, dry locations only
• System Compatibility: Single-Circuit T~TRAK™
• Maximum Cantilever Distance: 36 inches from wall
• Finish: White

Features

• Supports T~TRAK™ track lighting systems by extending from the wall to provide structural support
• Field-cuttable support rod allows for customized length adjustments using standard tools
• Includes aircraft cable and support post for secure installation at a minimum 45° angle
• Rigid standoffs recommended every four feet for stability
• Installation hardware includes threaded washers, anchors, and set screws for secure mounting
• Wire grip tab locks aircraft cable in position and allows trimming of excess cable for a clean appearance
• Compatible with white side of Single-Circuit T~TRAK™ track housing
