TECH LIGHTING 700TTBH9048W TT Horizontal 90° Curve 48 Inch Radius - Pre-Bent Track Lighting Solution

The TECH LIGHTING 700TTBH9048W is a pre-bent horizontal 90° curve section of the Single-Circuit T~TRAK track system designed for indoor dry locations. This line-voltage track system is hand-bendable and field-cuttable, providing flexible lighting solutions for commercial and residential applications. As an electrical distributor or switchgear supplier, this product supports a 20 amp rating and is compatible with lighting fixtures designed for the T~TRAK system. Its 48-inch radius curve enables smooth directional changes in track lighting layouts, ideal for wire and cable management in customized lighting installations.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part #: 700TTBH9048W
• Track Type: Single-Circuit T~TRAK
• Curve Radius: 48 inches
• Curve Angle: 90° horizontal
• Track Length (Linear): 92 inches
• Finish Color: White
• Current Rating: 20 amps
• Product Weight: 1.3 lbs
• Suitable Location: Indoor dry locations only

Features

• Pre-bent for precise 90° horizontal curve, facilitating easy installation
• Hand-bendable and field-cuttable for customized track layouts
• Includes two end caps to cover open ends for safety and aesthetics
• White finish with neutral on the white side and hot bus bar on the gray side for clear polarity
• Patented design (U.S. PAT. 7,172,332) ensuring quality and innovation
• ETL listed for safety compliance
• Compatible with single-circuit T~TRAK lighting systems
