TECH LIGHTING 700TTBH9048S TT Horizontal 90° Curve Track System

The TECH LIGHTING 700TTBH9048S is a pre-bent, single-circuit T~TRAK track system designed for indoor dry locations. It is a hand-bendable, field-cuttable, line-voltage track that supports lighting solutions with a 20 amp rating. This model features a horizontal 90° curve with a 48" radius and a satin nickel finish, suitable for creating precise track layouts in architectural and commercial lighting installations. It is ideal for electrical distributors and switchgear suppliers focusing on wire and cable management in lighting systems.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part #: 700TTBH9048S
• Track System: Single-Circuit T~TRAK
• Curve Radius: 48 inches
• Finish: Satin Nickel
• Length: 48 inches
• Product Weight: 1.3 lbs
• Electrical Rating: 20 Amps
• Application: Indoor dry locations only

Features

• Pre-bent horizontal 90° curve for easy installation and precise track layout
• Hand-bendable and field-cuttable for custom configurations
• Includes two end caps to cover open track ends
• White side is neutral, gray side is hot bus bar for clear polarity identification
• ETL listed and patented design (U.S. PAT. 7,172,332)
• Compatible with single-circuit T~TRAK lighting fixtures
• Do not install in wet or damp locations
