TECH LIGHTING 700SRT60DB SRT 600W 4-WIRE Transformer

The TECH LIGHTING 700SRT60DB SRT 600W 4-WIRE Transformer is a surface-mounted low-voltage magnetic transformer designed for use with Tech Lighting low voltage lighting systems. This transformer is suitable for indoor dry locations and is intended for mounting to a standard 4" junction box with a round plaster ring. It is commonly used by electrical distributors and switchgear suppliers for lighting solutions requiring reliable voltage transformation and dimming capability.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part Number: 700SRT60DB
• Input Voltage: 120V
• Output Voltage: 12V
• Wattage: 600 Watts (Low-Voltage Magnetic)
• Type: Surface Transformer
• Product Weight: 20.4 lbs
• UPC: 756460640866
• Finish: Black (with Chrome feeds)
• Dimensions: 9.1" diameter x 4.6" height (231 mm x 117 mm) [from catalog data on page 510]
• Certification: ETL Listed for indoor dry locations

Features

• Includes built-in dimming coil compatible only with low voltage magnetic dimmers
• Dual-feed transformer with isolating connectors included for safe power feed isolation
• Requires installation by qualified electrician with adherence to local electrical codes
• Mounts to a standard 4" junction box with round plaster ring (provided by electrician)
• Suitable for use at any height above finished floor in indoor dry locations
• Compatible with Tech Lighting low voltage lighting systems only
• Includes dome cover and mounting hardware for secure installation
• ETL listed for USA and Canada when used with Tech Lighting supplied products
