TECH LIGHTING 700SRT30DB SRT 300W XFMR W/DMC BLACK Surface Transformer

The TECH LIGHTING 700SRT30DB is a low-voltage magnetic surface transformer designed for indoor dry locations. It is intended for use with Tech Lighting low voltage lighting systems and is suitable for applications requiring a 300-watt transformer with 12V output. This transformer mounts to a standard 4" junction box with a round plaster ring and includes a built-in dimming coil compatible only with low voltage magnetic dimmers. It is a reliable component for electrical distributors and lighting solutions providers focusing on wire and cable and switchgear supply.

Specifications

• Manufacturer Part #: 700SRT30DB
• Input Voltage: 120V
• Output Voltage: 12V
• Wattage: 300 Watts
• Type: Magnetic AC
• Compatible Dimming Coil: Included
• Mounting: Surface mount to standard 4" junction box with round plaster ring
• Product Weight: 12.15 lbs
• Finish Color: Black
• ETL Listed for indoor dry locations only

Features

• Built-in dimming coil compatible with low voltage magnetic dimmers only
• Includes required feeds and plug option for installation
• Designed for use with Tech Lighting low voltage lighting systems
• Surface transformer cannot be placed directly between Wall MonoRail and the wall
• Installation requires qualified electrician and adherence to local electrical codes
• ETL listed for USA and Canada when used with Tech Lighting supplied products
• Supports maximum transformer load of 300 watts with magnetic dimming capability
