TECH LIGHTING 700SRT15DB SRT 150W Transformer for Low Voltage Lighting

The TECH LIGHTING 700SRT15DB is a 150-watt surface transformer designed for use with low voltage lighting systems. It operates on a 120V input and outputs 12V, suitable for magnetic low-voltage applications. This transformer is intended for indoor dry locations and is compatible with Tech Lighting low voltage lighting systems, making it an ideal component for electrical distributors and lighting solutions providers specializing in wire and cable and switchgear supply.

Specifications

• Manufacturer: Tech Lighting
• Model Number: 700SRT15DB
• Input Voltage: 120V
• Output Voltage: 12V
• Wattage: 150 Watts
• Type: Magnetic Low Voltage
• Weight: 7.2 lbs
• Finish: Black with Chrome feeds
• Certification: ETL Listed for USA and Canada
• Installation: Mounts to standard 4" junction box with round plaster ring (provided by electrician)
• Suitable Location: Indoor dry locations only

Features

• Built-in dimming coil compatible only with low voltage magnetic dimmers
• Includes mounting hardware and dome cover
• Requires one end or single-feed center power feed for installation
• Designed for use exclusively with Tech Lighting low voltage systems
• Installation must comply with local electrical codes and be performed by a qualified electrician
• Compatible with LED elements when used within recommended wattage limits
• Compact surface mount design for easy integration into lighting systems
