TECH LIGHTING 700PJCCMH39W PJ-CANOPY W/CMH BALLAST 39W WH Lighting Solutions

The TECH LIGHTING 700PJCCMH39W Power Jack Canopy with Ceramic Metal Halide (CMH) Ballast is designed for ceiling mount applications in indoor dry locations. It mounts to a standard 4" junction box with a round plaster ring or an octagon electrical box, making it suitable for integration into various electrical distributor projects. This canopy is intended exclusively for use with the Tech Lighting Power Jack system and compatible CMH heads, providing reliable lighting solutions for commercial and architectural lighting installations.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part Number: 700PJCCMH39W
• Wattage: 39 Watts
• Mounting: Ceiling mount only, mounts to 4" junction box with round plaster ring or octagon box
• Weight: 2.0 lbs
• Location: Indoor dry locations only
• Color/Finish: White
• UPC: 756460968380

Features

• Includes one Power Jack port for connection to Power Jack heads (sold separately)
• Compatible with line-voltage CMH heads designed for Power Jack system
• Installation requires qualified electrician; includes grounding provisions per local electrical codes
• Backplate mounts securely with #8-32 long screws and houses wiring connections
• Fixture head locks in permanent horizontal position with provided Allen wrench and set screw
• ETL listed for safety compliance
