TECH LIGHTING 700MOSRT60DZ MO SRT 600W W/DMC BRONZE Surface Transformer

The TECH LIGHTING 700MOSRT60DZ is a dual-feed surface transformer designed for low-voltage lighting systems. It is suitable for indoor dry locations and intended for use with Tech Lighting low voltage lighting solutions. This transformer provides magnetic AC output at 12 volts with a maximum wattage capacity of 1000 watts, making it a reliable component for electrical distributors and switchgear suppliers focusing on wire and cable and lighting solutions integration.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part #: 700MOSRT60DZ
• Input Voltage: 120V
• Output Voltage: 12V
• Wattage: 2 x 300 watts (600 watts total)
• Transformer Type: Magnetic AC
• Dimming: Compatible with low-voltage magnetic dimmers only
• Mounting: Surface mount to a standard 4" ceiling junction box with round plaster ring
• Dimensions: 9" (231 mm) diameter, 5" (127 mm) drop from ceiling
• Weight: 20.4 lbs
• Finish: Bronze
• Certifications: ETL listed

Features

• Dual-feed design with isolating connectors included for safe and flexible installation
• Built-in dimming coil compatible exclusively with low voltage magnetic dimmers to prevent transformer failure
• Designed for indoor dry locations and approved for installation at any height above finished floor
• Includes mounting hardware for installation by qualified electricians
• Compliant with local electrical codes and safety standards
• Supports integration with Tech Lighting MonoRail systems using isolating connectors
