TECH LIGHTING 700MOSRR15EW MO-REMOD TRNS 150W EL WH120/12 Transformer

The TECH LIGHTING 700MOSRR15EW Remodel Recessed Transformer is designed for low-voltage lighting systems, providing an integral power feed for clean installation above ceilings. Suitable for dry locations, this transformer installs similarly to remodel recessed downlights and is ideal for use in lighting solutions requiring a compact, concealed power source. It is compatible with Tech Lighting low voltage systems and is intended for professional electrical distributors and switchgear suppliers handling wire and cable applications in commercial or residential settings.

Specifications

• Input Voltage: 120V
• Output Voltage: 12V
• Wattage: 150 Watts
• Type: Electronic DC
• Product Weight: 2.02 lbs
• Compatible Dimmer Type: Low-voltage electronic dimmer
• Installation: Remodel recessed, installs above finished ceiling with 4.5” hole cut
• Safety Certification: ETL Listed for dry locations

Features

• Integral power feed eliminates need for separate power feed
• Fast-acting short circuit and overload protection with reset via wall switch
• Concealed transformer housing recessed above ceiling for a clean aesthetic
• Must be installed directly above the rail run with minimum 3 inches clearance from insulation
• Compatible only with Tech Lighting low voltage lighting systems
• Requires installation by a qualified electrician
• Not suitable for insulated ceilings
• White finish option includes satin nickel feed
