TECH LIGHTING 700MO2P4CDS MO2 Direct End Power Feed for Lighting Solutions

The TECH LIGHTING 700MO2P4CDS MO2 Direct End Power Feed is designed to supply power from a remote transformer to the rail at the end of a lighting run. It mounts to a standard 4" junction box with a round plaster ring, making it suitable for precise electrical installations in indoor dry locations. This product is ideal for electrical distributors and lighting solution providers integrating Two-Circuit MonoRail systems in commercial or architectural wire and cable applications.

Specifications

• Product Weight: 0.93 lbs
• Manufacturer: Tech Lighting
• Manufacturer Part #: 700MO2P4CDS
• Mounting: Standard 4" junction box with round plaster ring
• Location Suitability: Indoor dry locations only
• Junction Box Requirements: NEC compliant with minimum 2" depth and 6 cubic inches volume
• Certification: ETL Listed (Intertek)

Features

• Direct-end power feed mounts perpendicular to the rail at the end of the run
• Provides connection for Two-Circuit MonoRail lighting systems
• Includes canopy with red, black, and white wires for hot and common connections
• Canopy mounted with two #8-32 screws; universal round crossbar included for alignment
• Compatible with single-feed remote transformers
• Facilitates secure electrical connections with conductive rail connectors and set screws
