TECH LIGHTING 700FJPJRD11WS FJ-PJ WD CPY 11 RD W SN 120/12 Multi-Port Canopy

The TECH LIGHTING 700FJPJRD11WS is an 11-port round multi-port canopy designed for combination FreeJack and PowerJack lighting systems. This product serves as a versatile electrical distributor for lighting solutions, allowing integration of both low-voltage FreeJack ports and line-voltage PowerJack ports. It is intended for dry location installations and is suitable for use by switchgear suppliers and wire and cable professionals requiring multi-port canopy solutions.

Specifications

• Manufacturer: Tech Lighting
• Manufacturer Part #: 700FJPJRD11WS
• Product Weight: 29 lbs
• UPC: 884655147927
• System: 700 Series Combination FreeJack and PowerJack
• Shape: Round (RD11) 11-port canopy
• Material/Finish: Maple Wood with Satin Nickel Metal
• Mounting: Fits standard 4" junction box with round plaster ring (provided by electrician)
• Ports: 5 low-voltage FreeJack ports and 6 line-voltage PowerJack ports
• Installation: Includes drywall anchors for additional support
• Location Suitability: Dry locations only
• Certifications: ETL Listed for US

Features

• Combination canopy supports both low-voltage FreeJack and line-voltage PowerJack pendants
• Includes electronic transformers for all low-voltage ports
• Compatible with a wide range of FreeJack and PowerJack pendants (see manufacturer’s compatibility guidelines)
• Safety features include mounting to junction box with additional drywall anchors and safety cable attachment points
• Heat management recommendation: Maintain at least 12 inches clearance from wood canopy to any pendant or lamp head to prevent damage
• Optional set screw locking feature on PowerJack fixture heads for secure positioning
• Installation requires qualified electrician following local electrical codes
