Tamper-Resistant USB Receptacle, Type A/C, 20 Amp 125 Volt, Commercial Grade, Gray - Lev-Lok

This Lev-Lok combination tamper-resistant duplex Decora receptacle integrates dual-port USB Type A and Type C charging capabilities, designed for commercial and institutional applications. It provides a reliable electrical solution suitable for health care facilities, lobbies, airports, hospitality, and educational institutions. As a product from a trusted electrical distributor and switchgear supplier, it offers enhanced safety features and robust construction for demanding environments.

Specifications

• Device Type: Combination Device
• Amperage: 20 amperes
• Voltage: 125 VAC
• NEMA Configuration: 5-20R (WD-1)
• Number of Poles: 2
• Number of Wires: 3
• Grounding: Self-Grounding
• Dielectric Withstand Voltage: 2000 volts
• Horsepower Rating: 1 horse power
• Operating Temperature: -10¬∞C to 40¬∞C
• Face Material: Thermoplastic
• Body Material: PBT Thermoplastic polyester resin
• Flammability Rating: Rated V-0 per UL 94
• Mounting Strap: Galvanized Steel
• Ground Clip and Contacts: Brass
• Shutter Material: Thermoplastic
• Shutter Mechanism: Acetal
• Termination: Modular
• Strap Construction: Through-Strap
• Product Weight: 0.39 lbs
• Country of Origin: China
• Manufacturer: Leviton
• Manufacturer Part Number: M58AC-GY
• Grade: Commercial Specification
• Warranty: 5-Year Limited

Features

• Tamper-resistant shutters meet NEC Article 406.12 requirements for enhanced safety
• Dual USB ports (Type A and Type C) spaced to allow simultaneous use and reduce cable stress
• USB Type-C port provides faster charging aligned with emerging mobile device standards
• Impact and chemical resistant PBT face for extended service life
• Brass self-grounding clip ensures reliable grounding connection
• Improved mounting strap design provides greater mechanical support even with ears removed
• Compatible with most USB powered devices including tablets, smartphones, and laptops
• Certified to UL 498 and 1310, CSA C22.2 Nos. 42 and 223 standards
• Certified cCSAus and NOM-ANCE listings
