Features

• Powder Coat Painted Tile Furniture Feed Cover/Flange
• (1) ¾" Threaded Hub for Power and (1) 2" Threaded Hub for Data
• Includes (1) ¾" and (1) 2" Liquidtight Conduit Connectors
• Complies with ADA
• Cover/Flange; Cast Aluminum Construction; Durable Powder Coat Finish

Specifications

• Country of Origin: China
• Core Hole: 4 Inch SystemOne
• Cover Shape: Round
• Width: 4.900 in
• Each - Width: 4.900 in
• Industry Standard(s): cULus;UL514
• Mounting Method: To Fitting in Floor
• Service: Single; Multi
• Type of Use: Tile, Furniture Feed
• Typical Application: Tile, Furniture Feed
• Application: Flush SystemOne Installation
• Color: Brass
• Length: 5.62 in
• Number of Outlet: (1) 3/4" & (1) 1½" Threaded Hub Multi-Service
• Special Features: Cover/Flange; Cast Aluminum Construction; Durable Powder Coat Finish
• Standard: cULus;UL514
• Type: Sub Plate
• Cover Type: Furniture Feed
• Finish Type: Brass
• Number Of Outlets: (1) 3/4" & (1) 1½" Threaded Hub Multi-Service
• Style: Cover Flanges
• Description - Invoice: SUBPLATE, TILE FURN FEED, SYS 1, BRS
• Freight Class Code: 06168002
• Harmonization Code: 7616995190
• Image Actual Or Representative: A
• MSDS Flag: No
• Material - Mounting Hardware: Mounting Hardware Included
• Construction: Cast Aluminum
• Material: Aluminum
• Series: Flush - S1 Series
• Base Unit of Measure: EA
• BOX SIZE: 8.000x24.900x11.700 (in)
• Carton - Gross Weight per Pack: 15.350 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 00783585371825
• Carton - Total Units: 10 EA
• Case Weight: 14.150 lb.

Certifications

• EU RoHS Indicator: Contact Manufacturer
