Switches and Lighting Controls, Toggle Switch, Commercial Grade, Single Pole, 15A 120/277V AC, Back and Side Wired, Light Almond
SKU: #139294
Part: #CSB115LA
UPC: 783585153810
Switches and Lighting Controls, Toggle Switch, Commercial Grade, Single Pole, 15A 120/277V AC, Back and Side Wired, Light Almond
SKU: #139294
Part: #CSB115LA
UPC: 783585153810
Description
Switches and Lighting Controls, Toggle Switch, Commercial Grade, Single Pole, 15A 120/277V AC
This commercial spec grade toggle switch is designed for use in electrical distribution and lighting solutions. It features a single pole, 15 ampere rating suitable for 120/277V AC applications. The switch supports back and side wiring connections and is intended for indoor dry environments unless additional protection is provided. It is ideal for use by electrical distributors and switchgear suppliers seeking reliable, commercial-grade wire and cable control components.
Specifications
- Application: Commercial Spec Grade
- Current/Amperage: 15 amperes
- Voltage Rating: 120/277V AC
- Number of Poles: Single Pole
- Contact Rating: Per UL 20
- Operating Cycles: 50,000 Cycles
- Connection: Back and Side Wired
- Mounting: Screw Mount
- Material: Nylon
- Color: Almond
- Width: 1.910 in
- Contact Configuration: Two Position
- Environmental Conditions: Indoor Dry unless protected by additional means
- Product Weight: 0.1500 lbs
- Country of Origin: China
- Manufacturer: Hubbell Wiring Device-Kellems
- Manufacturer Part #: CSB115LA
- Action: Positive Snap
Features
- Commercial grade construction ensures durability and reliability in demanding applications
- Back and side wiring options provide installation flexibility for electrical distributors and contractors
- Positive snap action for clear tactile feedback during operation
- UL 20 contact rating for safety and compliance
- Designed for single pole switching to control lighting and electrical loads effectively
- Light almond color for aesthetic integration in commercial environments
