Switches and Lighting Controls, Industrial Grade, Locking Switches, General Purpose AC, Maintained Double Pole Double Throw Center Off , 20A 120/277V AC, Terminal Screws Black Key Guide
SKU: #141421
Part: #HBL1386L
UPC: 783585432687
Switches and Lighting Controls, Industrial Grade, Locking Switches, General Purpose AC, Maintained Double Pole Double Throw Center Off , 20A 120/277V AC, Terminal Screws Black Key Guide
SKU: #141421
Part: #HBL1386L
UPC: 783585432687
Description
Switches and Lighting Controls, Industrial Grade Locking Switches
This industrial grade locking switch is designed for general purpose AC applications with maintained double pole double throw (DPDT) action and a center off position. It supports inductive or resistive loads and is suitable for use by electrical distributors and switchgear suppliers requiring reliable control in lighting solutions and wire and cable systems. The switch features back and side wiring options and is engineered for durability and secure operation.
Specifications
- Application: Back and Side Wired
- Current: 20 amperes
- Amperage Rating: 20 A
- Load: Inductive or Resistive
- Contact Configuration: 3-Position
- Number of Poles: 2
- Action: DPDT
- Material: Composite
- Color: Black
- Width: 1.900 in
- Connection: Terminal Screws
- Mounting: Mounting Screws
- Lock Type: Non-Cylindrical
- Indicator: Dot Indicates On
- Contact Rating: Full Rated
- Made in USA: Yes
- Country Of Origin: United States
- Manufacturer Part #: HBL1386L
- Product Weight: 0.2500 lbs
Features
- Maintained double pole double throw switch with center off position for precise control
- Locking mechanism with double ended key actuator for enhanced security
- Back and side wired terminals for flexible installation
- Durable composite material construction ensuring long service life
- Terminal screws provide secure electrical connections
- Indicator dot clearly shows switch on position
- Full rated contacts suitable for industrial applications
- Manufactured in the USA ensuring quality and compliance
