Features

• Smooth, quiet rocker
• Low profile, less than 1 inch deep
• Self-grounding feature is standard
• Standard Product

Specifications

• Country of Origin: China
• Current / Amperage Rating: 15 A
• Width: 1.550 in
• Each - Width: 1.550 in
• Industry Standard(s): CSA Certified;UL Listed E3896
• Performance: Electrical - Dielectric voltage - Withstands 1,500V AC minimum for 1 minute;Electrical - Endurance - 30,000 cycles minimum;Electrical - Max. working voltage - 120V;Electrical - Overload - 1.5 times rating;Environmental - Flammability - UL V0;Environmental - Operating temperatures - Maximum continuous 60°C;minimum -20°C (without impact);Mechanical - Terminal accommodation - Back and side wire: #14 AWG min. - #12 AWG max. solid and stranded copper wire only;push wire: #14 AWG solid copper wire only
• Action: Snap Switch
• Actuator: Rocker
• Amperage Rating: 15 A
• Application: Residential
• Contact Configuration: Two Position
• Contact Rating: 15A
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Number of Poles: 2) Single Pole
• Operating Cycles: 30,000 Minimum
• Operating Temperature: Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
• Special Features: Standard Product
• Standard: CSA Certified;UL Listed E3896
• Voltage Rating: 120/277V AC kV
• Wattage: 4155
• Voltage Rating Description: 120/277V AC kV
• Conduit Connection: None
• Connectivity: Side Wired
• Display Size: Standard Size
• Number Of Poles: 2) Single Pole
• Description - Invoice: COMBO, 2) 15A SP ROCKER, WH
• Freight Class Code: 06168002
• Harmonization Code: 8536509040
• Image Actual Or Representative: A
• MSDS Flag: No
• Material - Mounting Hardware: Mounting Screws
• Current Rating: 15 A
• Base Unit of Measure: EA
• BOX SIZE: 2.500x9.000x4.400 (in)
• Carton - Gross Weight per Pack: 2.100 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 883778110214
• Carton - Total Units: 10 EA
• Case - Total Units: 50 EA
• Case Weight: 3.459 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 44.100 in
• Pallet Length: 48.000 in
• Pallet Weight: 1216.800 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: Yes
