SWITCH 30A 2P QP Molded Case Circuit Breaker

The Siemens SWITCH 30A 2P QP Molded Case Circuit Breaker is designed for electrical distribution applications requiring reliable circuit protection. This 2-pole, 120/240VAC breaker provides thermal magnetic trip protection, suitable for panelboard mounting in low voltage systems. It is ideal for electrical distributors and switchgear suppliers seeking durable and UL 489 listed molded case circuit breakers.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: B230S
• Voltage Rating: 120/240V AC
• Amperage Rating: 30A
• Number of Poles: 2
• Interrupt Rating: 10,000 AIC
• Trip Range: Thermal Magnetic
• Type: BL
• Dimensions (L x W x H): 4.00 in x 2.00 in x 3.00 in
• Product Weight: 0.72 lbs
• Country of Origin: Mexico
• Order Minimum: 1 unit

Features

• Panelboard mounting with INSTA-WIRE technology for fast and reliable connections
• Non-automatic switch design for standard circuit protection
• UL 489 and CSA certified for safety and compliance
• Thermal magnetic trip unit for accurate overload and short circuit protection
• Compact size suitable for space-saving electrical panels

Downloads & Links

• Spec Sheet
