Surecrimp Copper Compression Lug, Conductor Size 400, 1 Hole, #10 Bolt Size, Long Barrel, Sight Window, Narrow Tang, Tin Plated, UL, CSA
SKU: #253590
Part: #CLWN-400-10
UPC: 783669686838
Surecrimp Copper Compression Lug, Conductor Size 400, 1 Hole, #10 Bolt Size, Long Barrel, Sight Window, Narrow Tang, Tin Plated, UL, CSA
SKU: #253590
Part: #CLWN-400-10
UPC: 783669686838
Description
Surecrimp Copper Compression Lug, Copper Conductor Size 400 – Electrical Connector
The Surecrimp Copper Compression Lug is designed for secure electrical connections in wire and cable applications, suitable for electrical distributors and switchgear suppliers. This lug features a long barrel and narrow tang with a sight window for proper conductor insertion verification. It supports a 400 kcmil copper primary conductor and is rated for 35 kV, making it suitable for high-voltage electrical systems.
Specifications
- Material: Copper
- Plating: Tin
- Conductor Size: 400 kcmil
- Mounting Holes: 1
- Mounting Bolt/Stud Size: #10
- UL Listings: UL 486A/B, UL 467
- CSA Certification: C22.2 No. 65-03
- Connecting Angle: 180°
- Die Color Code: Blue
- Primary Color: Silver
- Die Index: I-76
- Flex Conductor Range: 300 G,H,I,K,M 313.1 DLO
- Rated Voltage: 35 kV
- Dimensions (L x W x H): 3.354 in x 0.922 in x 0.982 in
- Product Weight: 0.2490 lbs
Features
- Long barrel design for reliable conductor retention
- Narrow tang with square tang end for secure mounting
- Sight window to verify conductor insertion
- Tin plating for corrosion resistance
- UL and CSA listed for safety and compliance
