Surecrimp Copper Compression Lug, Conductor Size 300, 1 Hole, #10 Bolt Size, Long Barrel, Sight Window, Narrow Tang, Tin Plated, UL, CSA
SKU: #253564
Part: #CLWN-300-10
UPC: 783669686814
Surecrimp Copper Compression Lug, Conductor Size 300, 1 Hole, #10 Bolt Size, Long Barrel, Sight Window, Narrow Tang, Tin Plated, UL, CSA
SKU: #253564
Part: #CLWN-300-10
UPC: 783669686814
Description
Surecrimp Copper Compression Lug, Copper Wire and Cable Connector
The Surecrimp Copper Compression Lug by ILSCO is designed for secure electrical connections in wire and cable installations. This copper compression lug features a tin-plated connector with a long barrel and narrow tang, suitable for use by electrical distributors and switchgear suppliers requiring reliable conductor termination solutions. It is UL 486A/B and UL 467 listed, as well as CSA certified, ensuring compliance with industry safety standards. Its design includes a sight window for inspection and supports a 180° connecting angle, making it appropriate for various electrical and lighting solutions applications.
Specifications
- Conductor Size: 300 kcmil
- Mounting Holes: 1
- Mounting Bolt/Stud Size: #10
- Material: Copper
- Plating: Tin
- UL Listings: UL 486A/B, UL 467
- CSA Certification: C22.2 No. 65-03
- Connecting Angle: 180°
- Flex Conductor Range: 250 G, H
- Voltage Rating: 35 kV
- Die Color Code: White
- Primary Color: Silver
- Die Index: I-66
- Product Weight: 0.1710 lb
- Dimensions (inches): Length 3.149, Width 0.812, Tang Width 0.219, Tang Thickness 0.149
Features
- Long barrel design for enhanced conductor engagement
- Narrow tang with square tang end for precise fitting
- Sight window allows visual inspection of conductor insertion
- Tin plating provides corrosion resistance
- Single mounting hole simplifies installation with #10 bolt size
- Suitable for use with flexible conductors in the 250 G and H range
