Straight Solid Pin Terminal Connectors 750 MCM Awg Cable To 500 MCM Pin – Bi-Metallic Pin Terminals

These Straight Solid Pin Terminal Connectors are designed for reliable terminations between 750 MCM aluminum cable and 500 MCM copper pin. Manufactured from high-strength 6061-T6 aluminum alloy with electro tin plating, they are suitable for electrical distributors and lighting solutions requiring durable wire and cable connections. Their bi-metallic construction and AL9CU rating ensure compatibility with both copper and aluminum conductors, making them ideal for switchgear suppliers and other electrical applications.

Specifications

• Material: 6061-T6 Aluminum Alloy
• Wire Range: Conductor Size up to 750 MCM, Pin Size up to 500 MCM
• Voltage Rating: 600 V
• Color Coding: Yellow
• Manufacturer Part #: 90984
• Product Weight: 0.5850 lbs
• Certifications: UL, cUL, RoHS Compliant

Features

• Electro Tin Plated for Corrosion Resistance
• Oxide Inhibitor Coated Barrel to Prevent Oxidation
• EDPM Rubber Insulating Cover for Electrical Insulation
• AL9CU Rated for Use with Copper or Aluminum Conductors
• High Conductivity Aluminum Alloy Construction

Downloads & Links

• Spec Sheet
