Morris Products
Straight Solid Pin Terminal Connectors #6 Awg Cable To #4 Pin
SKU: #277289
Part: #90970
UPC: 601986909709
Morris Products
Straight Solid Pin Terminal Connectors #6 Awg Cable To #4 Pin
SKU: #277289
Part: #90970
UPC: 601986909709
Description
Straight Solid Pin Terminal Connectors #6 Awg Cable To #4 Pin – Bi-Metallic Pin Terminals
These Straight Solid Pin Terminal Connectors are designed for secure electrical connections between #6 AWG cable and #4 pin sizes. Manufactured from high-strength 6061-T6 aluminum alloy with electro tin plating, they ensure reliable performance for aluminum to copper cable terminations. Suitable for electrical distributors and lighting solutions requiring dependable wire and cable connections, these connectors feature an EDPM rubber insulating cover and are rated for use with copper or aluminum conductors.
Specifications
- Material: 6061-T6 Aluminum Alloy
- Color: Gray
- Voltage Rating: 600 V
- Wire Range: #6 AWG conductor to #4 pin size
- UL Certified: Yes
- cUL Certified: Yes
- RoHS Compliant: Yes
- Manufacturer Part #: 90970
- Product Weight: 0.1200 lbs
Features
- Electro Tin Plated for corrosion resistance
- AL9CU rated for copper or aluminum conductors
- Oxide inhibitor coated barrel to prevent oxidation
- EDPM rubber insulating cover for electrical insulation
- High strength, high conductivity aluminum alloy construction
