Straight Solid Pin Terminal Connectors 250 MCM Awg Cable To 3/0 Pin – Bi-Metallic Pin Terminals

These Straight Solid Pin Terminal Connectors are designed for reliable electrical connections between 250 MCM AWG cable and 3/0 pin size applications. Manufactured from high-strength 6061-T6 aluminum alloy with electro tin plating, they ensure optimal conductivity and corrosion resistance. Suitable for use by electrical distributors and switchgear suppliers, these connectors provide effective terminations for aluminum to copper cable transitions in lighting solutions and wire and cable installations.

Specifications

• Material: 6061-T6 Aluminum
• Color Coding: Red
• Voltage Rating: 600 V
• Manufacturer Part #: 90978
• Weight: 0.2400 lbs
• Wire Size: 250 MCM
• Pin Size: 3/0
• Pin Diameter: 0.594 in
• Total Length: 2.62 in
• Pin Length: 1.22 in
• Body Length: 1.40 in

Features

• Manufactured from high-strength, high-conductivity aluminum alloy
• Electro tin plated for enhanced corrosion resistance
• AL9CU rated for use with copper or aluminum conductors
• Oxide inhibitor coated barrel to prevent oxidation
• EDPM rubber insulating cover for electrical insulation

Downloads & Links

• Spec Sheet
