Morris Products
Straight Solid Pin Terminal Connectors #2 Awg Cable To #4 Pin
SKU: #277294
Part: #90972
UPC: 601986909723
Morris Products
Straight Solid Pin Terminal Connectors #2 Awg Cable To #4 Pin
SKU: #277294
Part: #90972
UPC: 601986909723
Description
Straight Solid Pin Terminal Connectors #2 Awg Cable To #4 Pin - Bi-Metallic Pin Terminals
These Straight Solid Pin Terminal Connectors are designed for reliable aluminum to copper cable terminations, suitable for electrical distributors and switchgear suppliers requiring durable wire and cable connections. Manufactured from high-strength, high-conductivity 6061-T6 aluminum alloy with an electro tin-plated finish, these connectors provide excellent conductivity and corrosion resistance for lighting solutions and other electrical applications.
Specifications
- Material: 6061-T6 Aluminum
- Color Coding: Pink
- Manufacturer Part #: 90972
- Voltage Rating: 600 V
- Wire Size: #2 AWG Cable
- Pin Size: #4
- UL Certified: Yes
- cUL Certified: Yes
- RoHS Compliant: Yes
- Product Weight: 0.1200 lbs
Features
- Manufactured from high-strength, high-conductivity aluminum alloy
- Electro tin plated for enhanced corrosion resistance
- AL9CU rated for copper or aluminum conductors
- Oxide inhibitor coated barrel to reduce oxidation
- EDPM rubber insulating cover for electrical insulation and protection
