Morris Products
Straight Solid Pin Terminal Connectors #1 Awg Cable To #3 Pin
SKU: #277301
Part: #90973
UPC: 601986909730
Morris Products
Straight Solid Pin Terminal Connectors #1 Awg Cable To #3 Pin
SKU: #277301
Part: #90973
UPC: 601986909730
Description
Straight Solid Pin Terminal Connectors #1 Awg Cable To #3 Pin – Bi-Metallic Pin Terminals
These Straight Solid Pin Terminal Connectors are designed for reliable electrical connections between #1 AWG cable and #3 pin terminals. Manufactured from high-strength 6061-T6 aluminum alloy with tin plating, they provide excellent conductivity and corrosion resistance. Suitable for use in wire and cable applications, these connectors facilitate Aluminum to Copper cable terminations, making them a practical component for electrical distributors and switchgear suppliers.
Specifications
- Material: 6061-T6 Aluminum
- Color Coding: Gold
- Voltage Rating: 600 V
- Manufacturer Part #: 90973
- Product Weight: 0.3000 lbs
- Wire Size: #1 AWG
- Pin Size: #3
Features
- Manufactured from high strength, high conductivity aluminum alloy
- Electro tin plated for corrosion resistance
- AL9CU rated for use with copper or aluminum conductors
- Oxide inhibitor coated barrel to prevent oxidation
- EDPM rubber insulating cover for electrical insulation
