Description
Straight Solid Pin Terminal Connectors 1/0 Awg Cable To #2 Pin – Aluminum Electrical Connectors
These Straight Solid Pin Terminal Connectors are designed for reliable electrical connections between 1/0 AWG cable and #2 pin size. Manufactured from 6061-T6 Aluminum with tin plating, they provide excellent conductivity and durability for use in wire and cable applications. Suitable for electrical distributors and switchgear suppliers, these connectors are ideal for aluminum to copper cable terminations in lighting solutions and other electrical systems.
Specifications
- Material: 6061-T6 Aluminum
- Color Coding: Tan
- Voltage Rating: 600 V
- Wire Range: 1/0 AWG cable to #2 pin
- Insulating Cover: EDPM Rubber
- UL, cUL, RoHS Certified
- Product Weight: 0.3000 lbs
- Manufacturer Part #: 90974
Features
- Manufactured from high strength, high conductivity aluminum alloy
- Electro tin plated for corrosion resistance
- AL9CU rated for copper or aluminum conductors
- Oxide inhibitor coated barrel for enhanced connection reliability
- EDPM rubber insulating cover for electrical insulation and protection
