Straight Blade Male Plugs 2 Pole 3 Wire 20A 125VAC Electrical Connector

This Straight Blade Male Plug is designed for electrical distribution and equipment power applications requiring a 20 amp, 125 VAC rating. It is suitable for use by electrical distributors and switchgear suppliers seeking reliable wire and cable connection solutions. The device ensures secure power delivery with a 2 pole, 3 wire configuration.

Specifications

• Amperage: 20 amperes
• Voltage: 125 VAC
• Poles and Wires: 2 Pole, 3 Wire
• Manufacturer: Morris Products
• Manufacturer Part #: 89614
• Product Weight: 0.2970 lbs
• UPC: 601986896146

Features

• Rugged nylon construction resists impact, abrasion, sunlight, and chemicals
• Grooved housing for enhanced grip
• All contacts are solid one-piece brass for superior conductivity and reduced heat rise
• Heavy duty contacts set in deep pockets to resist damage
• Heavy duty brass combo head terminal screws
• Clear terminal chamber allows visual inspection of terminals
• Cord strain relief and rubber grommet seal from environment
• Includes grounding screw

Downloads & Links

• Spec Sheet
