Description
Features
- Permanently marked with universal power symbol and the word "CONTROLLED" to visually identify receptacles used in automatic energy management systems
- Patented TR design eliminates plug-in difficulty and TR complaints
- Markings can be read regardless of mounting orientation
- Complies with NEC Section 406.3, ASHRAE 90.1, and California Title 24 requirements
- Complements Hubbell's Load:Logic® control system or other available energy management system
- Tamper Resistant
Specifications
- Country of Origin: China
- Current / Amperage Rating: 20 A
- Width: 1.900 in
- Each - Width: 1.900 in
- Industry Standard(s): UL Listed to UL498 File No. E2186Certified to CSA, C22.2, No. 42Fed. Spec. W-C-596NEMA® WD-6 Compliant
- Performance: Electrical: Current Interrupting- Certified for current interrupting at full rated current;Electrical: Dielectric Voltage- Withstands 2,000V minimum;Mechanical: Product Identification- Ratings are a permanent part of the device;Mechanical: Terminal Accommodation- #12-10 AWG stranded or solid copper wire only.;Mechanical: Terminal Identification- Terminals identified in accordance with UL 498 and CSA;Environmental: Flammability- UL 94V-2;Environmental: Operating Temperature- Maximum continuous 75°C;minimum -40°C (w/o impact)
- Amperage Rating: 20 A
- Application: Commercial Specification Grade
- Color: Red
- Dielectric Strength: Withstands 2,000V minimum
- NEMA Rating: 5-20R
- Number of Poles: 2-Pole
- Number of Wires: 3-Wire
- Special Features: Tamper Resistant
- Standard: UL Listed to UL498 File No. E2186Certified to CSA, C22.2, No. 42Fed. Spec. W-C-596NEMA® WD-6 Compliant
- Type: Tamper-Resistant
- Voltage Rating: 125 V
- Wire Size: #12 AWG to #10 AWG
- Voltage Rating Description: 125 V
- Connectivity: Back and Side Wired
- Display Size: Standard Sized Product
- Nema Rating: 5-20R
- Number Of Poles: 2-Pole
- Number Of Wires: 3-Wire
- Operating Temperature: Maximum continuous 75°C and minimum -40°C without Impact
- Style: Style Line Decorator
- Weight: 0.2 lb.
- Class Code: A04
- Description - Invoice: 1/2 CONTROLLED 20A 125V, B/S, TR DECO, R
- Freight Class Code: 06168002
- Harmonization Code: 8536698000
- Image Actual Or Representative: A
- MSDS Flag: No
- Sub Class Code: A04A060
- Material - Mounting Hardware: Screw Mounting
- Current Rating: 20 A
- Material: Nylon
- Series: Controlled
- Base Unit of Measure: EA
- BOX SIZE: 3.500x9.900x4.400 (in)
- Carton - Gross Weight per Pack: 2.000 lb.
- Carton - Number of Sub Packs: 10
- Carton - Pack Description: Carton
- Carton - SCC-14 Next Lower Level Sub Pack: 00783585583013
- Carton - Total Units: 10 EA
- Case - Total Units: 100 EA
- Case Weight: 20.000 lb.
Certifications
