This Hubbell Wiring Device-Kellems straight blade receptacle is designed for heavy duty industrial applications, providing reliable electrical connections for 20 ampere, 250 volt circuits. It is a specification grade, single receptacle with 2-pole 3-wire grounding, suitable for use in indoor dry environments unless additional protection is applied. This product is ideal for electrical distributors and switchgear suppliers requiring durable and compliant wiring devices for industrial wire and cable installations.

Specifications

• Manufacturer: Hubbell Wiring Device-Kellems
• Manufacturer Part #: HBL5461GY
• Application: Heavy Duty Industrial
• Amperage Rating: 20 A
• Current: 20 amperes
• Voltage: 250 Volts
• NEMA Rating: 6-20R
• Number of Poles: 2-Pole
• Number of Wires: 3-Wire
• Horsepower Rating: 2 horse power (AC only)
• Material: Thermoplastic/Composite
• Color: Gray
• Mounting: Screw Mount
• Connection: Back and Side Wired Screw Terminals
• Dielectric Strength: Withstands 2,000V minimum
• Width: 1.9 in
• Product Weight: 0.15 lbs
• Country of Origin: United States
• Made in USA: Yes
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means

Features

• Specification grade for industrial and commercial wiring applications
• Back and side wired screw terminals for secure connections
• Durable thermoplastic/composite construction for long service life
• Meets NEMA 6-20R configuration for 20A, 250V receptacles
• Withstands dielectric strength of 2,000 volts minimum
• Designed for mounting with standard screw mount method
• Color-coded gray finish for easy identification
• Manufactured in the USA ensuring quality and compliance
• Supports 2 HP motor loads at 20 amperes
