Features

• Tailored for EV Charging: This receptacle is purpose-built to cater to the specific needs of EV charging. It incorporates features and specifications that are optimized for the safe and efficient charging of electric vehicles.
• Industrial-Grade Construction: This EV receptacle boasts a robust and durable construction. It is engineered using high quality materials that can withstand demanding environments, ensuring long-lasting performance and reliability.
• Secure Connection: Terminal box shields against loose wires and external damage with a durable enclosure. Features a clamping mechanism for tight, efficient wire termination, reducing power loss or overheating risks.
• Contact Force & Durability: Thick wall terminal box offers 50% greater contact force for secure connections, minimizing power interruptions. Designed for heavy use, it withstands frequent insertions and removals, ensuring lasting performance.
• Fast & Efficient Charging: Features a 3-pole, 4-wire grounding for secure EV charging, minimizing electrical faults. With a 50A, 125/250V rating, it ensures high-power, faster charging times, promoting safety and efficiency.
• Effortless Installation: This EV Charging Receptacle is designed for easy setup, featuring a straightforward wiring mechanism suitable for both professional electricians and DIY enthusiasts, ensuring a hassle-free installation process.
• Standard

Specifications

• Country of Origin: United States
• Current / Amperage Rating: 50 A
• Dimensions: 3.28 in x 2.25 in x 2.23 in
• Width: 2.500 in
• Each - Width: 2.500 in
• Height: 2.23 in
• Horsepower - Maximum: 3
• Industry Standard(s): UL, CSA, Fed Spec
• Length: 3.28 in
• Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-0;Environmental - IP Suitability - IP20;Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
• Amperage Rating: 50 A
• Application: Heavy Duty
• Color: Black
• Dielectric Strength: Withstands 2,000V minimum
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• NEMA Rating: 6-50R
• Number of Poles: 2-Pole
• Number of Wires: 3-Wire Grounding
• Phase: Single Phase
• Size: 3.28 in x 2.25 in x 2.23 in
• Special Features: Standard
• Standard: UL, CSA, Fed Spec
• Type: Receptacle
• Voltage Rating: 250 V
• Wattage: 12500 W
• Wire Size: #12 AWG to #4 AWG
• Voltage Rating Description: 250 V
• Connectivity: Back and Side Wired Screw Terminals
• Display Size: Standard Sized Product
• Nema Rating: 6-50R
• Number Of Poles: 2-Pole
• Number Of Wires: 3-Wire Grounding
• Operating Temperature: Maximum continuous 75°C and minimum -40°C without Impact
• Weight: 0.45 lb.
• Class Code: A04
• Description - Invoice: RCPT, 2P3W, 50A 250V, 6-50R, BK
• Freight Class Code: 06168002
• Harmonization Code: 8536694020
• Image Actual Or Representative: A
• MSDS Flag: No
• Replaced Catalog Number: 9367;HBL9367CN
• Sub Class Code: A04A080
• Material - Mounting Hardware: Screw Mounting
• Current Rating: 50 A
• Material: Thermoplastic/Composite
• Base Unit of Measure: EA
• BOX SIZE: 5.800x8.500x6.900 (in)
• Carton - Gross Weight per Pack: 4.750 lb.
• Carton - Number of Sub Packs: 10
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 783585015279
• Carton - Total Units: 10 EA
• Case Weight: 4.650 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 47.200 in
• Pallet Length: 48.000 in
• Pallet Weight: 1164.800 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: Yes
