Straight Blade Devices Receptacle GFCI – Commercial Hospital Grade Electrical Distributor

This Hubbell Wiring Device-Kellems Straight Blade Devices Receptacle is a commercial hospital grade GFCI designed for tamper-resistant and weather-resistant applications. Rated at 20A and 125V, it provides reliable ground fault protection with self-test technology suitable for indoor dry environments unless additional protection is applied. This device is ideal for use in commercial electrical distribution, lighting solutions, wire and cable installations, and as part of switchgear supplier offerings where safety and compliance with NEC standards are essential.

Specifications

• Application: Commercial Hospital Grade
• Current: 20 amperes
• Amperage Rating: 20 AMP
• NEMA Rating: 5-20R
• Number of Poles: 2-Pole
• Number of Wires: 3-Wire Grounding
• Color: Red
• Material: Composite
• Mounting: Screw Mount
• Connection: Screw Terminals
• Width: 2.048 in
• Product Weight: 4.1500 lbs
• Environmental Conditions: Indoor Dry unless protected by additional means
• Manufacturer: Hubbell Wiring Device-Kellems
• Manufacturer Part #: GFTWRST83R
• Country of Origin: China

Features

• Patented shutter design for tamper-resistant protection
• Meets NEC requirements for tamper-resistant (TR 517-18c) and weather-resistant (WR 406.9) applications
• UV and corrosion resistant for harsh and damp environments
• Patented AUTOGUARD® self-test technology for ongoing safety verification
• Protection against line and load reversal, preventing power to face or downstream if miswired
• Flush face with back and side wiring options and multiple drive screws for secure installation

Downloads & Links

• Spec Sheet
• Catalog Page Asset Reference
• Installation Manuals Asset Reference
• GFTWRST83R AutoCAD Drawing
• AUTOGUARD¬Æ Self Test Ground Fault Receptacles
• Duct Products Guide
• Healthcare Application Guide
• Warranty Document Asset Reference
• Catalog Full Asset Reference
• Sales Drawing Asset Reference
