Description
STL360HB Motion Sensor Floodlight by RAB - Lighting Solutions for Electrical Distributors
The STL360HB by RAB is a precision-engineered motion sensor floodlight designed for reliable outdoor lighting control. It integrates a Super Stealth 360 infrared sensor with twin die-cast HB101 bullet floodlights, pre-wired and assembled on a universal CU4 EZ plate. This product is suitable for electrical distributors and switchgear suppliers looking for advanced lighting solutions with superior detection coverage and energy efficiency. It accepts PAR-38 lamps up to 150 watts (lamps not supplied) and is ideal for security and area lighting applications in wet locations.
Specifications
- Manufacturer: RAB
- Model Number: STL360HB
- Voltage: 120 volts AC, 60 Hz
- Power Consumption: 1 watt
- Switching Capacity: 8 amps, 1000 watts incandescent @ 120 volts
- Surge Protection: Withstands up to 6000 volts
- Detection Pattern: 180° forward, 360° downward for total detection
- Time Adjustment: 5 seconds to 12 minutes
- Wide Sensitivity Control: Adjustable from 100% to 30%
- Evening Timer: Keeps lights on for 1-8 hours after dusk, then motion activated until dawn
- RF Immunity: Circuits fully shielded for maximum radio frequency immunity
- Color: Bronze
- Weight: 4.5 lbs
- Mounting: CU4 EZ universal plate for mounting on round, rectangular, or octagonal surface or recessed boxes
- Scanning LEDs: 3 LEDs continually scan back and forth as a security indicator
- Temperature Compensation: Sensitivity adjusts automatically for consistent detection in varying ambient temperatures
- Lens Masks: Customized press-apply lens masks included to reduce coverage
- UL Listed: Suitable for wet locations
- Warranty: 10-year sensor warranty
Features
- Super Stealth 360 sensor with dual HB101 bullet floods for wide, precise illumination
- Pre-wired and assembled on universal CU4 EZ plate for easy installation
- Protected manual override with auto reset to automatic mode at dawn
- Advanced detection logic minimizes false triggers
- Photoelectric control deactivates lights during daylight; fully adjustable for 24-hour operation or custom applications
- Can be wired in parallel with other sensors
- Buy American Act compliance available upon request
- Energy efficient with only 1 watt power consumption in sensor operation
