Description
STL200HBW Stealth Outdoor Security Sensor Floodlight
The STL200HBW is a precision-engineered outdoor security sensor floodlight designed for reliable motion detection and lighting control. It features a twin precision die-cast aluminum HB101 bullet floodlight assembly pre-wired on a universal CU4 cover plate. Ideal for electrical distributors and lighting solution providers, this unit accepts PAR38 lamps up to 150 watts (lamps not included) and is suitable for wet locations. The sensor offers a wide 200° detection pattern, making it effective for residential or commercial security lighting applications. It is compatible with standard mounting boxes and provides advanced features for energy-efficient, automatic lighting control.
Specifications
- Manufacturer: RAB
- Model Number: STL200HBW
- Voltage: 120 Volts AC, 60 Hertz
- Switching Capacity: 1000 watts incandescent @ 120 volts, 8 amps
- Power Consumption: 1 watt
- Surge Protection: Withstands up to 6000 volts
- Detection Pattern: 200° view
- Time Adjustment: 5 seconds to 12 minutes
- Sensitivity Control: Adjustable from 30% to 100%
- Photoelectric Control: Fully adjustable, deactivates lights during daylight, supports 24-hour operation or custom settings
- Construction: Precision die-cast aluminum floodlights with 1/2" NPS threaded arm and serrated locking swivel
- Lens Mask: Customized press-apply lens mask included to reduce coverage
- Weight: 4.2 lbs
Features
- UL Listed and suitable for wet locations
- Two flip logic wall switch manual override with auto reset at dawn, no extra wiring required
- RF Immunity: Circuits fully shielded for maximum radio frequency immunity
- Advanced detection logic minimizes false triggers
- Temperature compensation for consistent detection in hot and cold ambient temperatures
- Horizontal lock, no-tool joints for fast, error-free sensor aiming and installation
- LED detection indicator glows red at night for on-guard deterrence
- Color-matched vandal-resistant lens and grill
- Protected manual override with auto reset
- Can be wired in parallel
- 10-year sensor warranty
- Buy American Act compliance available upon request
