STL110HBW Lighting Sensor Floodlight

The STL110HBW by RAB is a precision die-cast aluminum floodlight sensor designed for outdoor lighting control. It integrates a STEALTH sensor with twin HB101 bullet floodlights, pre-wired and assembled on a universal CU4 cover plate. This lighting solution is suitable for electrical distributors and lighting solution providers seeking reliable sensor-activated floodlights for security and energy efficiency applications. It accepts PAR38 lamps up to 150 watts (lamps not supplied) and is UL listed for wet locations.

Specifications

• Manufacturer Part #: STL110HBW
• Color: White
• Weight: 4.5 lbs
• Voltage: 120 Volts AC, 60 Hertz
• Switching Capacity: 1000 watts incandescent @ 120 volts, 8 amps
• Power Consumption: 1 watt
• Surge Protection: Withstands up to 6000 volts
• Detection Angle: 110° view
• Time Adjustment: 5 seconds to 12 minutes
• Sensitivity Control: Adjustable from 100% to 30%
• Photoelectric Control: Fully adjustable, deactivates lights during daylight
• Construction: Precision die cast aluminum floodlights with 1/2" NPS threaded arm and serrated locking swivel
• LED Detection Indicator: Shows sensor detection status and provides "on-guard" deterrence
• UL Listed: Suitable for wet locations
• Warranty: 10 year sensor warranty

Features

• Temperature compensation for consistent detection in varying ambient temperatures
• Radio frequency immunity with fully shielded circuits
• Wall switch manual override with automatic reset at dawn
• Advanced detection logic to minimize false triggers
• Horizontal lock with no-tool joints for easy sensor leveling
• Color matched vandal resistant lens and grill
• Protected manual override with auto reset
• Can be wired in parallel for multiple fixtures
