SR-505 Cord Connector – Electrical Cord Connector

The SR-505 Cord Connector by O-Z Gedney is designed for securing and sealing cords and cables entering enclosures or raceways. It provides a watertight and oiltight connection, suitable for use by electrical distributors and switchgear suppliers requiring reliable cord and cable entry solutions.

Specifications

• Application: For Securing And Sealing Cords And Cables Entering Enclosures Or Raceways
• Material: Malleable Iron, PVC Grommets
• Finish: Zinc Plated
• Cord Size: 0.5 inches
• Connection: MNPT
• Conductor Range: 0.4 - 0.5 inches
• Product Weight: 0.1500 lbs
• Manufacturer: O-Z Gedney
• Manufacturer Part #: SR-505

Features

• Tapered threaded male hub NPT
• Watertight and oiltight design
• UL Listed NEMA 4 and 6 when installed into a NPT threaded entry or UL Listed conduit hub (sizes 1¼” and larger require thread sealant)
• Rated for temperatures up to +90 °C (+194 °F)

Downloads & Links

• Catalog
