Morris Products
Split Bolt Connectors With Spacer For Copper Conductors 500MCM
SKU: #276499
Part: #90366
UPC: 601986903660
Morris Products
Split Bolt Connectors With Spacer For Copper Conductors 500MCM
SKU: #276499
Part: #90366
UPC: 601986903660
Description
Split Bolt Connectors With Spacer For Copper Conductors 500MCM - Electrical Connectors
The Split Bolt Connector with Spacer is designed for secure electrical connections in copper conductors up to 500 MCM. Manufactured by Morris Products, this connector is suitable for electrical distributors and wire and cable applications requiring reliable mechanical and electrical performance. It offers a robust solution for lighting solutions, switchgear suppliers, and other electrical installations needing high conductivity and secure wire combinations.
Specifications
- Material: High conductivity electrolytic copper
- Nut Material: Bronze
- Voltage Rating: 600 V
- Wire Range: #8 Stranded through 500 MCM
- Catalog Number: 90366
- Product Weight: 1.2470 lbs
- UPC: 601986903660
- UL Certified: Yes
- cUL Certified: Yes
- RoHS Compliant: Yes
Features
- Manufactured from high strength, high conductivity electrolytic copper
- Bronze nut for enhanced durability
- Electro tin plated for corrosion resistance
- Compatible with copper and copperweld stranded wire
- Free running thread with easy grip hex nut for efficient installation
- Ribbed separator provides excellent pullout force resistance
- Secure connection for all wire combinations within specified range
