Morris Products
Split Bolt Connectors With Spacer For Copper Conductors 3/0
SKU: #276487
Part: #90360
UPC: 601986903608
Morris Products
Split Bolt Connectors With Spacer For Copper Conductors 3/0
SKU: #276487
Part: #90360
UPC: 601986903608
Description
Split Bolt Connectors With Spacer For Copper Conductors 3/0 - Electrical Connector
The Split Bolt Connector with Spacer is designed for secure electrical connections in copper conductors, suitable for wire sizes ranging from #8 stranded through 500 MCM. Manufactured by Morris Products, this connector is ideal for electrical distributors and lighting solutions providers requiring reliable wire and cable connections. It features high conductivity electrolytic copper construction with a bronze nut, ensuring durability and optimal electrical performance in various switchgear and wiring applications.
Specifications
- Material: High conductivity electrolytic copper
- Nut Material: Bronze
- Voltage Rating: 600 V
- Wire Range: #8 Stranded through 500 MCM
- UPC: 601986903608
- Product Weight: 0.5250 lbs
- Manufacturer Part #: 90360
- Certifications: UL, cUL, RoHS
Features
- Manufactured from high strength, high conductivity electrolytic copper
- Bronze nut with electro tin plating for corrosion resistance
- Compatible with copper and copperweld stranded wire
- Free running thread with easy grip hex nut for installation efficiency
- Ribbed separator provides excellent pullout force resistance
- Secure connection for all wire combinations within specified range
