Description
Split Bolt Connectors With Spacer Dual Rated For Copper & Aluminum Conductors 500MCM
These split bolt connectors are designed for secure electrical connections in wire and cable applications, suitable for both copper and aluminum conductors up to 500 MCM. Manufactured by Morris Products, they provide reliable conductivity and mechanical strength for electrical distributors and switchgear suppliers requiring dual-rated connectors for mixed conductor types.
Specifications
- Material: 6061-T6 Aluminum Alloy
- Conductor Size: 4/0 to 500 MCM
- Temperature Rating: 75°C
- Voltage Rating: 600 V
- Finish: Electro-Tin Plated
- UL Certification: UL 486B Dual Rated
- CSA Certification: Yes
- Product Weight: 0.9660 lbs
- Manufacturer Part #: 90426
- UPC: 601986904261
Features
- High strength, high conductivity aluminum alloy construction
- Electro-tin plating for corrosion resistance
- CU-AL dual rating for compatibility with aluminum and copper conductors
- Conductor spacer accommodates dissimilar conductor types
