Morris Products
Split Bolt Connectors For Copper Conductors #8
SKU: #276411
Part: #90314
UPC: 601986903141
Morris Products
Split Bolt Connectors For Copper Conductors #8
SKU: #276411
Part: #90314
UPC: 601986903141
Description
Split Bolt Connectors For Copper Conductors #8 – Copper Electrical Connector
The Split Bolt Connector #8 by Morris Products is designed for secure electrical connections of copper conductors ranging from size #8 up to 750 kcmil. Suitable for grounding and bonding applications, this connector is UL 467 listed for direct burial, ensuring reliable performance in demanding electrical installations. Ideal for electrical distributors and lighting solutions providers requiring robust wire and cable connectors.
Specifications
- Conductor Size: #8 to 750 kcmil
- Material: Body – High Strength Electrolytic Copper; Nut and Spacer – Copper Alloy
- Temperature Rating: 75°C
- Voltage Rating: 600 V
- UL Certification: UL 467 Listed for Direct Burial
- CSA Certification: Yes
- Product Weight: 0.0560 lbs
- UPC: 601986903141
- Manufacturer Part Number: 90314
Features
- Manufactured from high-strength, high-conductivity copper alloy for durability and optimal electrical performance
- UL 467 listed for direct burial and grounding/bonding applications
- Compatible with copper and Copperweld stranded cable only
- Includes conductor spacer to accommodate dissimilar conductors
