Morris Products
Split Bolt Connectors For Copper Conductors 750MCM
SKU: #276475
Part: #90334
UPC: 601986903349
Morris Products
Split Bolt Connectors For Copper Conductors 750MCM
SKU: #276475
Part: #90334
UPC: 601986903349
Description
Split Bolt Connectors For Copper Conductors 750MCM – Electrical Connectors
The Split Bolt Connectors for Copper Conductors 750MCM by Morris Products are designed for secure mechanical and electrical connections of copper conductors in electrical distribution and grounding applications. These connectors are suitable for wire and cable installations requiring reliable conductivity and durability, making them ideal for electrical distributors and switchgear suppliers handling copper cable connections.
Specifications
- Material: Body - High Strength Electrolytic Copper; Nut and Spacer - Copper Alloy
- Conductor Size: #8 to 750 MCM
- Temperature Rating: 75°C
- Voltage Rating: 600 V
- UL Listing: UL 467 Listed for Direct Burial and Grounding/Bonding
- CSA Certified: Yes
- Product Weight: 2.25 lbs
- UPC: 601986903349
Features
- Manufactured from high strength, high conductivity copper alloy for optimal electrical performance
- UL 467 listed for direct burial and grounding/bonding applications
- Designed exclusively for copper and CopperWeld stranded cable
- Includes conductor spacer to accommodate dissimilar conductors ensuring secure connections
