Split Bolt Connectors For Copper Conductors 500MCM - Electrical Connectors

The Split Bolt Connectors for Copper Conductors 500MCM by Morris Products are designed to provide secure and reliable electrical connections for copper and copperweld stranded wire in various wire ranges. These connectors are suitable for use by electrical distributors and switchgear suppliers requiring dependable wire and cable joining solutions for lighting and power distribution applications.

Specifications

• Material: High conductivity electrolytic copper
• Nut Material: Bronze
• Voltage Rating: 600 V
• Wire Range: #8 Stranded through 750 MCM
• UPC: 601986903325
• Product Weight: 1.0780 lbs
• Manufacturer Part #: 90332
• Certifications: UL, cUL, RoHS compliant

Features

• Manufactured from high strength, high conductivity electrolytic copper for optimal electrical performance
• Bronze nut with free running thread and easy grip hex design for secure and efficient installation
• Ribbed separator enhances pullout force resistance, ensuring a stable connection
• Compatible with multiple wire combinations within the specified range for versatile application

Downloads & Links

• Spec Sheet
