Morris Products
Split Bolt Connectors For Copper Conductors 350MCM
SKU: #276470
Part: #90330
UPC: 601986903301
Morris Products
Split Bolt Connectors For Copper Conductors 350MCM
SKU: #276470
Part: #90330
UPC: 601986903301
Description
Split Bolt Connectors For Copper Conductors 350MCM – Electrical Connectors
The Split Bolt Connector for Copper Conductors 350MCM by Morris Products is designed for secure electrical connections in wire and cable applications. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable connections for copper and copperweld stranded wire within a wide wire range. This connector supports electrical systems up to 600 volts and is ideal for various lighting solutions and electrical distribution installations.
Specifications
- Material: High conductivity electrolytic copper
- Nut Material: Bronze
- Voltage Rating: 600 V
- Wire Range: #8 Stranded through 750 MCM
- Manufacturer Part #: 90330
- Product Weight: 0.75 lbs
- UL Certified: Yes
- cUL Certified: Yes
- RoHS Compliant: Yes
Features
- Manufactured from high strength, high conductivity electrolytic copper
- Bronze nut for enhanced durability
- Free running thread with easy grip hex nut for simplified installation
- Ribbed separator provides excellent pullout force resistance
- Secure connection for all wire combinations within the specified range
