Specifications

General

• Application: For Limited Space Applications
• Color Code: Red
• Connector Type: Splice
• Die Index: 49
• Feature - Barrel Style: Chamfered
• Feature - Barrel Type: Standard
• Material: Copper
• Plated: Y
• Plating Type: Tin - Electro Plated
• Sub Brand: HYLINK
• Trade Name: HYLINK™
• Type: YS-L, Standard Barrel
• UPC: 781810022092
• UPC 12 Digit: 7818100220922

Dimensions

• Dimension - B Length fraction: 7/16 in
• Dimension - B Length inch: 0.44 in
• Dimension - L Length Overall mm: 25 mm
• Dimension - Length Overall inch: 1.00 in
• Dimension - Outside Diameter inch: 0.27 in
• Dimension - Strip Length inch: 1/2

Electrical Ratings

• Rating - KVA: 35 kV
• Rating - Minimum Voltage: 600
• Voltage - Maximum: 35000

Conductor Related

• Conductor - Copper Str Aircraft Size: AN 8
• Conductor - Copper Str Navy Size: 23 (7)
• Conductor - Copper Str Size: 8 AWG

Certifications and Compliance

• Certification - CSA Approved: Yes
• Certification - ETL: No
• Certification - UL Recognized: No
• Certification - cULus: No
• Industry Standard(s): UL486A-UL486B
• Standards - Industry Standards Met: UL486A-486B
• Standards - RoHS Compliance Status: CM
• UL Listed: Yes

Logistics

• Carton Quantity: 600 EA
• Minimum Pack Quantity: 50
