SOUTHWIRE 104622 2IN PVC 22-1/2DEG ELB PLAIN END
SKU: #399837
Part: #104622
UPC: 751338868960
SOUTHWIRE 104622 2IN PVC 22-1/2DEG ELB PLAIN END
SKU: #399837
Part: #104622
UPC: 751338868960
Description
SOUTHWIRE 104622 2IN PVC 22-1/2DEG ELB PLAIN END - PVC Conduit Elbow
The Southwire 104622 is a 2-inch Schedule 40 PVC 22-1/2 degree plain end elbow designed for electrical conduit installations. This fitting is suitable for use by electrical distributors and contractors requiring reliable conduit bends for wire and cable management. It is compatible with Schedule 40 and Schedule 80 PVC conduit systems and can be used in both above-ground and buried applications, including concrete encasement.
Specifications
- Manufacturer Part #: 104622
- Size: 2 inch
- Material: Schedule 40 PVC
- Weight: 0.547 lbs
- UPC: 751338868960
Features
- Longer radius than standard UL elbows
- Both ends are spigot (plain) end
- Both ends are solvent weld
- Suitable for use in concrete encasement
- Meets NEMA TC 3 requirements
- Seal is watertight
