Features

• Butt hinges on door
• Flush slotted latch operated with a screwdriver; optional latches available
• Weldnuts provided for mounting optional panels
• Butt hinges
• Mounting holes on back of enclosure

Specifications

• Length: 7.90 inch
• Width: 8.40 inch
• Height: 6.20 inch
• Weight: 6.10 pound
• Height (H) (inch): 8
• Height (H) (millimetre): 203
• Width (W) (inch): 8
• Width (W) (millimetre): 203
• Depth (D) (inch): 6
• Depth (D) (millimetre): 152
• Protection Rating: NEMA Type 1
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness (T) (gauge): 16
• Thickness (T) (millimetre): 1.52
• Panel Size (D x E) (inch): 6.25 x 6.25
• Panel Size (D x E) (millimetre): 159 x 159
• Panel: A8N8P
• Perforated Panel: A8N8PP
• NEMA Rating: 1 Indoor, electrical protection
• Modification Services: Yes
• Type Number: Type 1
• IP Rating: IP30
• Weight (pound): 6.1
• Size: 8.00x8.00x6.00 in
