Features

• Butt hinges on door
• Flush slotted latch operated with a screwdriver; optional latches available
• Weldnuts provided for mounting optional panels
• Butt hinges
• Mounting holes on back of enclosure

Specifications

• Length: 6.30 inch
• Width: 6.50 inch
• Height: 4.00 inch
• Weight: 4.00 pound
• Height (H) (inch): 6
• Height (H) (millimetre): 152
• Width (W) (inch): 6
• Width (W) (millimetre): 152
• Depth (D) (inch): 4
• Depth (D) (millimetre): 102
• Protection Rating: NEMA Type 1
• Material: Mild Steel
• Finish: Powder Coated
• Color: Gray
• Color Code: ANSI 61
• Thickness (T) (gauge): 16
• Thickness (T) (millimetre): 1.52
• Panel Size (D x E) (inch): 4.25 x 4.25
• Panel Size (D x E) (millimetre): 108 x 108
• Panel: A6N6P
• Perforated Panel: A6N6PP
• NEMA Rating: 1 Indoor, electrical protection
• Modification Services: Yes
• Type Number: Type 1
• IP Rating: IP30
• Weight (pound): 4
• Size: 6.00x6.00x4.00 in
