Description
SM7R15830120W LED Surface Mount Downlight
The SM7R15830120W is a 7-inch round LED surface mount downlight designed for retrofit and new installations in residential and commercial lighting applications. It provides efficient, uniform illumination with a warm color temperature, suitable for use by electrical distributors and lighting solutions providers. This fixture is compatible with standard 4" junction boxes and supports TRIAC dimming for flexible lighting control, making it an ideal product for wire and cable and switchgear suppliers looking to offer energy-efficient lighting options.
Specifications
- Input Voltage: 120 volts
- Input Wattage: 15 watts
- Lumens: 1,293 lumens
- Efficacy: 60 lumens per watt
- Color Temperature: 3000 kelvins (Warm)
- Color Accuracy: 80 CRI
- Lens Material: Diffuse Polystyrene
- Product Weight: 0.8 lbs
- Minimum Starting Temperature: -22 degrees Fahrenheit
- Maximum Ambient Temperature: 104 degrees Fahrenheit
- Beam Angle: 120°
- Lifespan: 50,000 hours (based on IES LM-80 and TM-21)
- Power Factor: ≥0.9
- Dimming: TRIAC compatible, dimming as low as 5%
- Mounting: Torsion springs for retrofit, compatible with most 4" junction boxes
- Finish: Matte White
- Housing: Durable aluminum with non-electrically conductive polycarbonate frame
- Certifications: UL Listed & Classified for wet locations, IC Rated, Air Tight (ASTM E283), ENERGY STAR® Version 2.2 Certified
Features
- Suitable for direct contact with insulation (IC Rated)
- Air Tight housing certified to ASTM E283 standards
- Cold weather starting capability down to -22°F
- Diffuse polystyrene lens for smooth, glare-free light distribution
- Includes Edison 26 Medium Base Socket adapter and mounting bracket for secure installation
- Mercury and UV free, RoHS-compliant components supporting green technology
- Warranty: 5 years covering light output, color stability, driver performance, and finish
- Buy American Act compliance available upon request
